Jig Checking Fixture
Khoom loj: 98 * 49 * 37mm
Khoom siv: Aluminium, Bronze, Bronze, Copper, Hardened Hlau, Stainless hlau, Hlau Alloys
Khoom Specification
|
Khoom npe |
jig xyuas fixture |
|
Yam khoom No. |
HTCK-004 |
|
Khoom loj |
98 * 49 * 37mm |
|
Khoom siv |
Aluminium, Brass, Bronze, Copper, Hardened Hlau, Stainless hlau, Hlau Alloys |
|
Qhov tseeb |
0 005-0.1 mm los yog ntawm koj qhov kev thov |
|
Xim |
Anodized, aluminium xim, dub lossis ib tus neeg tuaj yeem ua raws li tus neeg thov |
|
Kev kho saum npoo |
Xuab zeb blasting, kev kho cua sov, xuab zeb blasting, kev kho cua sov, thiab lwm yam |
|
Cov cuab yeej siv tshuab |
CNC, EDM, Argie Charmilles, Milling Tshuab, 3DCMM, |
|
Txoj Kev Logo |
Laser engraving, CNC engraving |
|
Kev siv |
Auto Checking Fixture |
|
Ntim |
Ntoo lub thawv los yog ntawm koj qhov kev thov |
|
Chaw kuaj mob |
Peb lub koom haum ntsuas tshuab, Micrometer, calipers |
|
Lub sijhawm ua haujlwm |
15-20hnub tom qab cov qauv pom zoo |
Jig Checking fixture Taw qhia
HT Tool&Die tau muab ntau lub jig checking fixture rau kev lag luam tsheb. Lub peev xwm ntawm peb lub tsev jig kuaj xyuas fixture thiab cov cuab yeej tsim cov chaw ua kom yooj yim jigs thiab ntau qhov kev sib tw tsim kom haum rau cov neeg siv khoom xav tau. fixtures muaj nyob rau hauv txhua qhov ntau thiab tsawg, cov duab thiab cov khoom siv raws li tus neeg siv khoom xav tau.
Jig Checking Fixture thiab Check Gauge rau High Precision Automotive Fitting Parts
Nws yog siv los nrhiav cov khoom sib dhos. Nws yog siv los tshawb xyuas qhov ceev thiab intuitively, mating nto, contours thiab lwm yam tseem ceeb nta nrog ib tug tes ntsuas los xyuas seb cov khoom puas tsim nyog.
Nws muaj qhov zoo hauv qab no
- Tus nqi pheej yig
- Kev pabcuam zoo tom qab muag
- High positioning raug
- High khoom zoo thiab shipping efficiency
Peb Lub Tuam Txhab Peev Xwm
Engineering Peev Xwm
Kev sib tw zoo
Software Automation
UG theem nrab kev txhim kho tsis siv neeg tsim ua kom muaj txiaj ntsig ntau dua 30% ;
Tsim Standardization.
90% cov khoom sib xyaw ua ke yog tus qauv tsim thaum lub sij hawm tsim kom luv luv txhuas-lub sij hawm thiab txo nqi;
Cov neeg siv khoom xav tau & txaus siab.
Txhawm rau kom nkag siab zoo dua cov neeg siv khoom tshwj xeeb thiab qhov yuav tsum tau ua, kev tshuaj xyuas tech hauv tus neeg thiab kev txhawb nqa hauv zos ntawm qhov chaw muaj rau loj.
Muaj Peev Xwm Ntau Lawm
- 80-800T tshuab xovxwm tshuab
- Tooling manufacturing peev: 10sets (15tons ntawm tooling)
- Khoom siv: Hlau, Stainless hlau, Aluminium, tooj liab, tooj dag
- 30 hnub ceev pwm xa tuaj
- OEM kev pabcuam customized rau cov neeg siv khoom
Quality Control Peev Xwm
- 8 tus neeg ua haujlwm puv sijhawm hauv chav haujlwm
- CMM ntsuas tshuab
- 3D xiav lub teeb scanner
- ISO9001 kev tswj hwm qhov system ntawv pov thawj
- R & R daim ntawv qhia thiab SGS daim ntawv qhia muaj
Delivery Control Peev Xwm
- Txhua qhov kev txiav txim yog npaj ua ntej
- Daim ntawv tshaj tawm txhua lub limtiam lossis ncua sijhawm yog muab txhua lub limtiam
- Yog tias muaj qhov txawv txav hauv kev tsim khoom, peb yuav ntsuas ib zaug.
- Nyob rau hauv rooj plaub ntawm kev xa khoom qeeb, peb yuav them tus nqi logistics
Daim ntawv pov thawj
FAQ
Q: Dab tsi yog jig check fixture?
Q: Yuav ua li cas los tsim ib lub jig check fixture?
Q: Lub hom phiaj tseem ceeb ntawm jig check fixture yog dab tsi?
Q: Dab tsi yog lub hauv paus ntsiab lus ntawm jig thiab fixture?
Q: Vim li cas jigs thiab fixtures tseem ceeb?
