Tshawb xyuas Cov Cheebtsam Fixture

Yam khoom No:HTCK-001
Khoom loj: 105 * 52 * 48mm
Khoom siv: Aluminium, tooj liab, thiab epoxy resin

Xa kev nug

Khoom Taw qhia

Khoom Specification

Khoom npe	Tshawb xyuas cov khoom sib txuas
Yam khoom No.	HTCK-001
Khoom loj	105 * 52 * 48mm
Khoom siv	Aluminium, tooj liab, thiab epoxy resin
Qhov tseeb	0 005-0.1 mm los yog ntawm koj qhov kev thov
Xim	Anodized, aluminium xim, dub lossis ib tus neeg tuaj yeem ua raws li tus neeg thov
Kev kho saum npoo	Xuab zeb blasting, kev kho cua sov, xuab zeb blasting, kev kho cua sov, thiab lwm yam
Cov cuab yeej siv tshuab	CNC, EDM, Argie Charmilles, Milling Tshuab, 3DCMM,
Txoj Kev Logo	Laser engraving, CNC engraving
Daim ntawv thov	Auto Parts manufacturers thiab auto factories
Ntim	Ntoo lub thawv los yog ntawm koj qhov kev thov
Chaw kuaj mob	Peb lub koom haum ntsuas tshuab, Micrometer, calipers

Xyuas fixture Taw qhia

Ib qho kev kuaj xyuas fixture yog ib qho kev ruaj ntseg zoo siv hauv kev lag luam los xyuas qhov zoo ntawm cov khoom nrog cov duab nyuaj. Cov neeg tsim khoom nrhiav kev pab hauv kev tshuaj xyuas cov khoom siv los tshuaj xyuas qhov tseeb ntawm lawv cov khoom. Lawv kuj tshuaj xyuas cov khoom sib txawv, khawb thiab xyuas seb cov khoom puas raug raws li qhov xav tau, thiab lees paub tias cov khoom ua tau raws li txhua yam tsim nyog kev nyab xeeb thiab cov lus qhia tshwj xeeb.

Cov yam ntxwv thiab hom kev kuaj xyuas Fixtures

CMM Fixtures yog ib yam ntawm Cov Khoom Siv Hluav Taws Xob uas tau tsim los tuav thiab tso qhov chaw, sojntsuam, lossis cov khoom ua haujlwm thaum lub sijhawm ntsuas qhov ntev thiab lwm yam kev ntsuas kev ua haujlwm ntawm Lub Tshuab Ntsuas Ntsuas (CMM).

Qhov tseem ceeb ntawm Kev Tshawb Fawb Fixtures hauv Automotive

Cov Cheeb Tsam Fixtures yog ib qho tseem ceeb ntawm Kev Pov Hwm Zoo hauv kev tsim cov khoom lag luam xws li tsheb thiab dav hlau. Cov khoom siv kuaj xyuas niaj hnub no tso cai rau tus neeg teb xov tooj tuaj yeem tshawb xyuas qhov ntsuas sab hauv lossis sab nrauv ntawm qhov ntsuas lossis cov ntsiab lus kom pom tias nws tau tsim nyob rau hauv qhov kev zam ntawm tus qauv tsim. Nws tuaj yeem muaj ob peb lub clamps, pins, sojntsuam, lossis lwm yam cuab yeej txuas rau lub rooj sib dhos thiab cov txheej txheem meej ntawm cov lus qhia ib ntus los xyuas kom meej tias tsis hais tus neeg teb xov tooj ntawm qhov khoom siv yog leej twg, qhov tshwm sim ntawm daim tshev yuav yog. tib yam.

Kev siv hauv Kev Tsim Khoom

Automotive Parts Assembly:

Kev kuaj xyuas cov khoom sib txuas yog siv dav hauv kev lag luam tsheb lossis lwm yam kev lag luam los xyuas qhov ntev ntawm cov khoom xws li chassis ntsiab, thiab cov khoom siv sab hauv. Lawv xyuas kom meej tias cov khoom haum ua ke kom raug thaum sib dhos thiab ua tau raws li cov qauv kev ua tau zoo.

Kev tsim khoom loj ib puag ncig:

Yog tias muaj ntau qhov zoo ib yam lossis cov khoom zoo sib xws raug tsim, kev kuaj xyuas cov khoom siv tau txais txiaj ntsig zoo rau kev ua kom muaj kev sib haum xeeb thiab raug. Qhov no yog qhov tseem ceeb heev rau kev ua tiav cov hom phiaj tsim khoom yam tsis muaj kev cuam tshuam rau qhov zoo.

Hloov cov cuab yeej tshwj xeeb ntsuas:

Kev kuaj xyuas cov khoom siv ua haujlwm ua ntau yam rau cov cuab yeej ntsuas tshwj xeeb xws li ntsaws ntsuas thiab OD ntsuas. Lawv muab kev yooj yim hauv kev ua haujlwm thaum tseem xa cov kev ntsuas raug, ua rau lawv haum rau ntau yam kev tsim khoom siv hauv tsheb, aerospace, hluav taws xob thiab lwm yam ...

Cov txiaj ntsig ntawm Kev Siv Kev Tshawb Fawb Fixtures

Kev txuag nqi:Kev tshuaj xyuas cov khoom siv kho mob feem ntau pheej yig dua li cov cuab yeej ntsuas tshwj xeeb, txo cov peev peev hauv cov cuab yeej tshuaj xyuas.
Yooj yim siv:Lawv tau tsim los ua tus neeg siv khoom zoo, yuav tsum muaj kev cob qhia tsawg heev rau cov neeg ua haujlwm los ua kev tshuaj xyuas zoo.
Kev ntseeg tau:Kev kuaj xyuas cov khoom siv los yog ntsuas ntsuas muab kev ntsuas zoo ib yam thiab rov ua dua, ua kom muaj kev ntseeg siab hauv cov txheej txheem tswj kom zoo.
Scalability:Haum rau ob qho tib si me me thiab loj-loj ntau lawm ib puag ncig, gauges hloov mus rau qhov sib txawv ntau lawm thiab cov kev xav tau.

Vim li cas thiaj xaiv HT cuab yeej

Nov yog qee qhov laj thawj tseem ceeb los xaiv HT cov cuab yeej rau koj cov khoom siv kuaj xyuas:

Hwm Zoo: High-precision processing machines yuav xyuas kom meej tias cov khoom siv hauv cov khoom siv tau zoo.

Tus nqi sib tw: Hauv tsev machining ntxiv rau kev koom tes ntev nrog cov khoom siv thiab cov khoom siv thib ob, ua kom peb muaj kev ruaj ntseg zoo kom txuag tau tus nqi.

Txaus siab lav:ISO9001 ntawv pov thawj rau cov tshuab zoo yuav ua rau cov neeg siv khoom txaus siab rau peb cov khoom.

Saj zawg zog Customization:Cov kev pabcuam OEM lossis cov kev daws teebmeem yog muaj raws li cov neeg siv khoom xav tau.

Fast Turnaround Sijhawm:Lub voj voog luv luv thiab xa tawm raws sijhawm nrog kev tswj xyuas nruj kom paub tseeb tias lub sijhawm xa khoom.

Kev Pab Cuam: Kev tswj xyuas qhov project muaj zog thiab kev paub txog engineering ua kom zoo tshaj plaws.

FAQ

Q: Dab tsi yog kev kuaj xyuas fixtures?

A: Cov khoom siv kuaj xyuas yog cov cuab yeej pov thawj zoo siv hauv kev lag luam los kuaj xyuas cov khoom zoo nrog cov duab nyuaj. Lawv tsis yog siv los ua cov khoom siv tab sis lees txais lossis tsis lees txais cov khoom uas twb tau ua lawm raws li qhov raug.

Q: Dab tsi yog qhov txawv ntawm lub teeb thiab lub ntsuas hluav taws xob?

A: Hauv kev sib piv rau lub ntsuas ntsuas, lub ntsuas ntsuas tuaj yeem tuav cov khoom siv lossis cov khoom ua haujlwm raug kuaj xyuas kom ruaj ntseg hauv qhov kev xav tau zoo heev. Tsis tas li ntawd, nws kuj tseem tuaj yeem ua raws li tus lej ntsuas thiab lwm yam cuab yeej ua haujlwm, xws li nrhiav tus pins, jigs, thiab clamps.

Q: Dab tsi yog qhov tseem ceeb ntawm kev kuaj xyuas cov khoom siv?

A: Cov khoom tseem ceeb ntawm cov khoom siv tshuaj ntsuam xyuas suav nrog lub hauv paus (phaj) thiab cov rooj tog zaum lossis zes, so / tiv tauj cov ntsiab lus, thiab tuaj yeem suav nrog clamps, nres, nqus tsev, hlau nplaum, thiab pneumatic.

Q: Dab tsi yog qhov tseem ceeb ntawm cov khoom siv kuaj xyuas?

A: Tshwj xeeb tshaj yog nyob rau hauv kev ua hauj lwm tsheb, xyuas fixtures, los yog "checking aids," los yog check fixture Cheebtsam, raws li lawv raug xa mus rau hauv tus txheej txheem PPAP, feem ntau yog ib tug hybrid ntawm ob. Lawv tuaj yeem tsim los tuav cov khoom rau CMM tshuaj xyuas, piv txwv li, thiab suav nrog cov chaw uas sib haum rau cov ntaub ntawv ntawm GD&T schemes lossis lub tsheb txoj haujlwm ntawm daim duab. Cov khoom siv tib yam yuav suav nrog cov ntsuas uas muab cov ntaub ntawv ntsuas qhov sib txawv ncaj qha rau qee yam nta.

Q: Gage Repeatability & Reproducibility yog dab tsi (Gage R & R)

A: Gage Repeatability thiab Reproducibility feem ntau hu ua Gage R & R. Nws yog ib txoj hauv kev los ntsuas qhov rov ua dua thiab rov ua dua ntawm kev ntsuas qhov system thaum koj siv cov khoom siv kuaj xyuas. Hauv lwm lo lus, Gage R & R kev tshawb fawb tau ua tiav los tshawb pom ntau npaum li cas ntawm cov txheej txheem kev hloov pauv vim qhov ntsuas qhov system.

Q: Nws txawv li cas ntawm BIW fixture?

A: Txawm hais tias ob qho tib si tau siv ntau hauv kev lag luam tsheb, muaj qhov sib txawv me ntsis ntawm lawv. BIW (Lub Cev Hauv Dawb) fixture yog cov cuab yeej tsim khoom uas tuav 3-qhov seem ua ke uas yuav tsum tau welded. Hauv kev lag luam tsheb, cov khoom siv tshuaj xyuas yog siv los tshuaj xyuas cov khoom kawg ntawm cov ntawv hlau lub cev xws li thaum txhua qhov chaw ntawm lub tsheb chassis tau muab tso rau hauv BIW fixture, lawv raug muab tso rau ib leeg.
