Xyuas Fixture

High Quality Checking Fixture Supplier-HT Tool & Tuag

Mus dhau qhov tsuas yog tsim cov stamping tuag thiab pwm, HT Tool & Tuag tuaj yeem tsim kho cov khoom siv los yog ntsuas los kuaj xyuas cov hlau stamping qhov chaw rau peb cov txheej txheem stamping. Txhua qhov kev soj ntsuam ntsuas cov cuab yeej & kuaj xyuas cov khoom siv yog CMM thiab 3D scanner kuaj thiab txheeb xyuas kom tau raws lossis tshaj peb cov neeg siv khoom xav tau tshwj xeeb thiab kam rau ua.

01/

Pab neeg tshaj lij:Peb tsim kom muaj kev paub txog engineering thiab cov kws tshaj lij pab neeg ua haujlwm kom ntseeg tau tias txhua feem ntawm kev kuaj xyuas raug xa mus rau peb cov neeg siv khoom tiav.

02/

Kev tswj qhov project:Peb tsom rau kev tswj xyuas qhov project muaj zog kom xa cov ntsuas zoo rau peb cov neeg siv khoom raws sijhawm. Peb pawg tswj hwm tau koom nrog thiab ua haujlwm ncaj qha los ntawm RFQ mus rau PPAP theem.

03/

Kev pabcuam customized:Peb yuav sib txuas lus zoo nrog txhua tus ntawm peb cov neeg siv khoom thiab kawm seb lawv xav tau dab tsi los ua kev daws teeb meem rau lawv tus kheej.

04/

Teb ceev:Tsis muaj teeb meem thaum koj xa peb cov lus nug lossis kev tsis txaus siab, peb tuaj yeem teb tam sim raws li tus neeg siv khoom thov.

05/

Tsis txhob tso cai rau cov menyuam yaus uas tsis muaj kev saib xyuas cov neeg laus siv cov khoom no ib leeg, cov menyuam yaus yuav tsum tsis txhob cia cov menyuam yaus nyob ib leeg nrog cov khoom siv ntxiv, kev pheej hmoo ntawm txhaws.

Khoom Taw Qhia

Kev kuaj xyuas fixture lawv tau siv rau kev kuaj xyuas-kev lees paub zoo thiab kev pom zoo tom qab lossis tsis lees paub cov khoom tsim tau raws li qhov tseeb qhov tseeb.Thiab lawv lees paub tias cov khoom ua raws li txhua yam tsim nyog kev nyab xeeb thiab specifications.HT Tool checking fixture muaj qhov ntsuas qhov tseeb yam tsis muaj deformation, tsis tshua muaj nqi txij nkawm thiab zoo yooj yim.Cia peb saib yuav ua li cas xyuas fixtures feem ntau ua hauj lwm.

Daim ntawv thov hauv Manufacturing:

Automotive Parts Assembly:

Kev kuaj xyuas cov khoom siv tau dav siv hauv kev lag luam tsheb lossis lwm yam kev lag luam los xyuas qhov ntev ntawm cov khoom xws li chassis ntsiab, thiab cov khoom siv sab hauv. Lawv xyuas kom meej tias cov khoom haum ua ke kom raug thaum sib dhos thiab ua tau raws li cov qauv kev ua tau zoo.

Kev tsim khoom loj ib puag ncig:

Yog tias muaj ntau qhov zoo ib yam lossis cov khoom zoo sib xws raug tsim, kev kuaj xyuas cov khoom siv tau txais txiaj ntsig zoo rau kev ua kom muaj kev sib haum xeeb thiab raug. Qhov no yog qhov tseem ceeb heev rau kev ua kom tau raws li cov hom phiaj tsim khoom yam tsis muaj kev cuam tshuam rau qhov zoo.

Hloov cov cuab yeej tshwj xeeb ntsuas:

Kev kuaj xyuas cov khoom siv ua haujlwm ua lwm txoj hauv kev rau cov cuab yeej ntsuas tshwj xeeb xws li plug gauges thiab OD gauges. Lawv muab kev yooj yim hauv kev ua haujlwm thaum tseem xa cov kev ntsuas raug, ua rau lawv haum rau ntau yam kev tsim khoom siv hauv tsheb, aerospace, hluav taws xob thiab lwm yam ...

Cov txiaj ntsig ntawm Kev Siv Tshuaj Xyuas Fixtures:

Kev Txuag Nqi: Kev txheeb xyuas cov khoom siv feem ntau pheej yig dua li cov cuab yeej ntsuas tshwj xeeb, txo cov peev peev hauv cov cuab yeej tshuaj xyuas. Kev Siv Yooj Yim: Lawv tau tsim los ua tus neeg siv khoom zoo, yuav tsum muaj kev cob qhia me me rau cov neeg ua haujlwm kom ua tau zoo. Kev ntseeg tau: Kev tshuaj xyuas cov khoom siv los yog cov ntsuas ntsuas muab kev ntsuas zoo ib yam thiab rov ua dua, ua kom muaj kev ntseeg siab hauv cov txheej txheem tswj kom zoo. Scalability: Haum rau ob qho tib si me me thiab loj qhov chaw tsim khoom, gauges hloov mus rau qhov sib txawv ntau lawm thiab yuav tsum tau ua.

Kev ua haujlwm ua ntu zus ntawm kev kuaj xyuas fixture

Cov kauj ruam hauv qab no piav qhia luv luv piav qhia txog txoj hauv kev los ua kom ntseeg tau qhov zoo thiab qhov tseeb ntawm qhov tsim khoom siv cov khoom siv kuaj xyuas. Txhua kauj ruam yog qhov tseem ceeb rau kev tswj xyuas cov qauv zoo thiab ua kom cov khoom ua tau raws li cov neeg siv khoom xav tau thiab cov lus qhia tshwj xeeb.

Kev soj ntsuam pom cov kauj ruam no yog txhawm rau txheeb xyuas sab nraud ntawm cov khoom siv kuaj xyuas yog tias muaj cov npoo ntse, tawg, thiab burrs.
Txheeb xyuas qhov loj ntawm qhov: Siv GO thiab NOGO pins los xyuas qhov loj ntawm qhov.
Ua Qhov Zoo rau Kov: Datum pins, net-pads, thiab hlau nplaum yog siv los xyuas kom meej qhov chaw raug thiab tuav ruaj ntseg nyob rau hauv qhov chaw hauv qhov chaw kuaj xyuas. Cov kauj ruam no ua kom qhov tseeb thiab rov ntsuas dua.
Kho qhov chaw: Kho qhov chaw kom nws zoo tiv tauj nets thiab loacate nrog X / Y1 / Z1 thiab Y2 / Z2.
Kaw clamps: Kaw clamp Z1, Z2, Z3.
Qhov Kev Ntsuas Qhov Chaw: Siv P1 tus pins los xyuas qhov chaw ntawm lub qhov.
Txheeb xyuas qhov sib tw & qhov chaw: Siv lub ntsuas qhov ntsuas thiab ntsuas qhov ntsuas los xyuas qhov luas thiab nto raws li cov ntsiab lus xim.
Visual Edge Detection: Pom pom ntawm ntug ntawm cov khoom, nws tsim nyog nyob rau hauv +/-1.5 kab, thiab vice versa.
Cov txiaj ntsig tau sau tseg: Sau cov txiaj ntsig ntawm daim ntawv tshuaj ntsuam xyuas.Cov ntaub ntawv no yog qhov tseem ceeb rau kev tswj xyuas kom zoo thiab taug qab.
Unclamping thiab tshem tawm ib feem.Thaum kev tshuaj xyuas tiav thiab cov txiaj ntsig tau sau tseg, cov clamps raug tso tawm, thiab cov khoom raug tshem tawm ntawm qhov kev kuaj xyuas. Qhov no ua tiav cov txheej txheem tshuaj xyuas rau qhov tshwj xeeb ntawd.

Lus Cim:Lub checking fixture / gauges yuav tsum nyob rau hauv ib puag ncig tsis muaj plua plav nrog qhov ntsuas kub thiab av noo ruaj khov thaum lawv siv los tshuaj xyuas cov khoom.Rau txhua qhov kev kuaj xyuas fixtures, HT cov cuab yeej yuav xa ib phau ntawv qhia nrog rau cov khoom xa tuaj.

Qhov zoo ntawm Kev Tshawb Xyuas Fixtures hauv Manufacturing

Kev kuaj xyuas cov khoom siv ua lub luag haujlwm tseem ceeb hauv kev tsim khoom lag luam xws li hlau stamping lossis txhaj tshuaj yas, pab xyuas kom cov khoom ua tau raws li cov kev xav tau thiab cov qauv. Lawv muaj qhov zoo hauv qab no:

Nws txo lossis qee zaum tshem tawm cov kev siv zog ntawm kev cim, ntsuas, thiab teeb tsa lub tshuab ua haujlwm ntawm lub tshuab, ua kom cov khoom tsim tau zoo.
Ua kom cov machining raug thiab xyuas kom muaj kev sib hloov.
Ua kom cov khoom tsim tau ntau dua vim qhov nce ntawm cov noob, pub, thiab qhov tob ntawm kev txiav, vim jigs thiab fixtures muab siab clamping rigidity.
Ua kom cov khoom tsim tau ntau dua vim muaj peev xwm ntawm kev ua haujlwm ob lossis ntau lub workpieces ib txhij lossis tus lej ntawm cov cuab yeej txiav.
Txuag cov neeg ua haujlwm los ntawm kev txo cov kev tuav tuav.
Nws yooj yim rau kev khiav lag luam, Semi-skilled zog txaus.
Nce versatility ntawm tshuab cuab yeej.
Lub workpiece thiab cov cuab yeej muaj nyob rau ntawm lawv cov haujlwm raws nraim ua ntej kev ua haujlwm tau txais nyob rau hauv lub sijhawm tsis txaus. Yog li nws txo cov khoom lag luam lub sijhawm.
Variability ntawm dimension nyob rau hauv huab hwm coj ntau lawm yog tsawg heev yog li kev tsim cov txheej txheem txhawb los ntawm kev siv jigs thiab fixtures tuav ib tug zoo ib yam.
Nws txo lub sij hawm voj voog ntau lawm thiaj li ua kom muaj peev xwm ntau lawm.
Ua hauj lwm nrog ntau tshaj ib lub cuab yeej ntawm tib lub workpiece yog ua tau.
Tsis muaj qhov xav tau ntxiv los tshuaj xyuas qhov loj ntawm cov khoom lag luam yog tias qhov ua haujlwm zoo ntawm cov jigs thiab cov khoom siv tau raug lees paub, yog li qhov no yuav txuag lub sijhawm ntawm kev kuaj xyuas zoo.

Hom Kev Tshawb Fawb Cov Khoom Siv

Cov hlau loj dua yog sib dhos los ntawm kev siv lubkev sib dhos fixtures.
Adjustable fixturestuaj yeem siv rau hauv lub tshuab dhos qhov twg cov cuab yeej txiav sib txawv tuaj yeem ua kom haum rau ib qho kev teeb tsa.
Cov khoom sib tsoonws muab qhov tseeb rau kev sib tsoo qhov chaw xws li kev sib txuas, pas nrig, lub zog, thiab cov khoom siv.
Cov welding fixturesuas yog siv los tuav cov khoom uas yuav tsum tau rau shaping thiab nws yog siv los ntawm qhov me me mus rau qhov loj.

Yuav Ua Li Cas Tsim thiab Tsim Kev Tshawb Xyuas Fixture / Gauge.

Kev tsim thiab tsim cov khoom siv kuaj xyuas yog cov kauj ruam tseem ceeb ntawm kev ua kom muaj tseeb hauv cov txheej txheem tsim khoom, nrog rau kev tsim ib qho yuav tsum tau ua tib zoo npaj, ua tib zoo saib xyuas kom meej thiab kev paub tob txog engineering hauv paus ntsiab lus. Nov yog qee cov kauj ruam uas yuav pab tau koj los ntawm txoj kev no.

Ua ntej tshaj plaws, kev sib sau cov ntaub ntawv yuav tsum suav nrog qhov ntev, kam rau ua, thiab cov kev cai tshwj xeeb lossis cov yam ntxwv uas yuav tsum tau kuaj xyuas.
Thaum ib tus qauv 3D CAD ntawm koj feem tau tsim los siv software tshwj xeeb, siv cov qauv no los ua lub hauv paus rau kev tsim nws cov khoom kuaj xyuas. Kev tsom mus rau kev sib koom ua ke cov ntsiab lus siv thiab ua kom muaj kev nkag mus rau cov cuab yeej ntsuas yog qhov tseem ceeb rau nws txoj kev tsim ua tiav.
Tom qab tus qauv CAD tiav lawm, pib tsim koj lub fixture siv cov ntaub ntawv tsim nyog xws li txhuas lossis hlau. Ua kom ruaj khov, rigidity thiab yooj yim ntawm kev sib dhos sab saum toj ntawm lub siab nyob rau theem ntawm kev tsim. Fixtures yuav tsum muaj cov yam ntxwv kom raug qhov chaw rau kev ntsuas. Siv cov ntaub ntawv pov thawj los ntawm kev kos duab engineering kom paub meej cov chaw no.
Xav txog suav nrog ntau lub ntsuas lossis ntsuas ntsuas hauv koj qhov kev kuaj xyuas tsim kom ua tiav cov kev ntsuas raug, los ntawm qhov yooj yim mus / tsis mus gauges mus rau ntau txoj hauv kev tshawb nrhiav hluav taws xob lossis lub zeem muag.
Ua ntej ua tiav koj tus qauv tsim, ua virtual simulations yog tias ua tau kom pom tias muaj peev xwm cuam tshuam lossis sib tsoo nrog lwm yam khoom siv thaum lub sijhawm ua haujlwm thiab xyuas kom muaj kev ua haujlwm thiab txo nqi rov ua haujlwm tom qab. Ua qhov no yuav pab lav qhov ua tau zoo thaum pab tiv thaiv cov nqi rov ua dua tom qab.
Thaum tus tsim tau pom zoo, digitally txheeb xyuas nws kom huv si ua ntej mus tom ntej nrog fabrication. CNC Machining cov tswv yim zoo li milling drilling tig tuaj yeem siv nrog cov cuab yeej siv tes xws li pom cov ntaub ntawv laum los txiav cov duab thiab sib sau ua ke ib tus neeg raws li cov neeg siv khoom tshwj xeeb rau cov khoom sib dhos zaum kawg.

Cov khoom siv dav siv los kuaj xyuas cov khoom siv

Kev xaiv cov ntaub ntawv tsim nyog rau kev tsim thiab tsim cov khoom kuaj xyuas yog qhov tseem ceeb tshaj plaws hauv kev tsim lossis tsim kom tiav. Cov khoom siv yuav tsum muaj qhov zoo xws li durability, raug, thiab ruaj khov - ntawm no yog qee cov ntaub ntawv nquag siv:

Aluminium.
Hlau.
Cov khoom siv sib xyaw.
Yas 5. Epoxy Resins.

Kev Tswjhwm Zoo thiab Kev Txhim Kho ntawm Kev Tshawb Xyuas Fixtures

Kev tswj xyuas kom zoo yuav tsum muaj kev ntsuam xyuas ib ntus ntawm ib qho kev kuaj xyuas kom paub tseeb tias lawv ua haujlwm tau zoo, xws li kev ntsuas ntsuas tiv thaiv cov qauv paub, ua cov kev sim ua haujlwm thiab tshuaj xyuas qhov hnav lossis kev puas tsuaj. Qhov no tuaj yeem suav nrog kev tshuaj xyuas kev ntsuas tawm tsam cov qauv uas tau teev tseg rau lawv nrog rau kev sim ua haujlwm lossis tshuaj xyuas cov cim ntawm kev hnav lossis kev puas tsuaj.
Kev saib xyuas ua si yog qhov tseem ceeb hauv kev ua kom lub neej ntev ntawm kev kuaj xyuas cov khoom siv. Kev tu tsis tu ncua yuav tsum tshem tawm cov khib nyiab lossis cov kab mob uas tuaj yeem cuam tshuam nws txoj haujlwm; Tsis tas li ntawd, lubricating txav qhov chaw pab txo kev sib txhuam thiab hnav-thiab-tua.
Kev ntsuas tsis tu ncua kuj tseem yog qhov tseem ceeb rau kev tswj xyuas qhov ntsuas kom raug, yog li kev kuaj xyuas cov khoom siv yuav tsum tau calibrated ntawm lub sij hawm teem siv cov qauv siv traceable los xyuas kom meej tias lawv tseem muab cov kev nyeem meej.

Peb cov neeg siv khoom kawg

Peb Daim Ntawv Pov Thawj: Peb tau dhau ISO9001: 2015

iso

Peb Cov Khoom Siv

CMM

CNC

3D Scanner

Drilling

EDM

NYIAJ

FAQ

Q: Dab tsi yog qhov kev kuaj xyuas fixture tswvyim?

A: Cov khoom siv hluav taws xob yog cov cuab yeej siv hluav taws xob tsim los nrhiav, tuav, thiab txhawb nqa cov khoom thaum lub sijhawm tsim khoom. Nws yog tsim los ntawm amalgamating fixture lub cev, locators, kev txhawb nqa, thiab clamps. Kev kuaj xyuas cov khoom siv yog cov cuab yeej ua pov thawj zoo siv los ntawm kev lag luam los ntawm cov tuam txhab tsheb mus rau cov kws tsim cov hlau phais kom kuaj xyuas qhov zoo ntawm cov hlau stamping lossis cov khoom yas uas muaj cov duab geometrical complex.

Q: Dab tsi yog cov yam ntxwv ntawm lub teeb pom kev zoo?

A: Rau kev nrhiav cov khoom ua haujlwm, cov khoom siv siv tus pins (lossis cov nyees khawm), clamps, thiab qhov chaw. Cov khoom no xyuas kom meej tias lub workpiece yog positioned kom raug, thiab tseem nyob rau hauv tib txoj hauj lwm nyob rau hauv lub lag luam.

Q: Dab tsi yog qhov kev kuaj xyuas fixture tsim?

A: Fixtures yog cov cuab yeej ua haujlwm tsim los tuav, nrhiav thiab txhawb nqa cov khoom ua haujlwm thaum tsim khoom. Fixtures muab ib txoj hauv kev los siv thiab kho cov cuab yeej txiav rau lub workpiece tab sis lawv tsis coj cov cuab yeej.

Q: Dab tsi yog qhov sib txawv ntawm qhov kev xeem jig thiab lub fixture?

A: Lub jig tswj thiab coj cov cuab yeej txiav mus ua haujlwm ntawm qhov chaw ua ntej ntawm lub workpiece. Fixtures yog siv los txhawb thiab nrhiav ib lub workpiece. Fixtures tsis coj cov cuab yeej ntawm lub workpiece zoo li jig.

Q: Yuav ua li cas kuaj cov khoom siv ua haujlwm?

A: Fixtures txhais cov kauj ruam thiab cov ntaub ntawv uas tsim cov theem ntawm kev xeem. Hauv HT Tool&Die, lawv yog cov haujlwm uas koj txhais tau tias ua haujlwm rau lub hom phiaj no. Lawv kuj tuaj yeem siv los txheeb xyuas qhov kev xeem ua theem; qhov no yog cov txheej txheem muaj zog rau kev tsim cov kev sim ntau dua.

Q: Dab tsi yog daim ntawv tshuaj ntsuam xyuas ntawm lub tshuab kuaj xyuas?

A: Daim ntawv tshuaj ntsuam xyuas yog ib qho cuab yeej tseem ceeb rau cov neeg soj ntsuam thiab cov kws tshaj lij thoob plaws ntau qhov kev lag luam. Cov npe tshuaj xyuas pab ntsuas kev ua raws li cov txheej txheem, txheej txheem, khoom siv, lossis chaw ua haujlwm nrog kev lag luam, tsoomfwv, lossis cov qauv sab hauv.

Q: Dab tsi yog qhov txawv ntawm qhov ntsuas thiab ntsuas qhov ntsuas?

A: Ib qho kev kuaj xyuas zoo ib yam li lub ntsuas ntsuas tshwj tsis yog tias nws tuaj yeem tuav qhov nws ntsuas. Nws tuaj yeem ua raws li tus naj npawb ntawm cov cuab yeej ntsuas ntsuas thaum tuav qhov yuav tsum tau kuaj xyuas.

Q: Dab tsi yog cov ntsiab lus tseem ceeb ntawm kev tshuaj ntsuam xyuas?

A: Cov khoom siv tseem ceeb ntawm kev tshuaj ntsuam xyuas suav nrog lub hauv paus (phaj) thiab cov rooj tog zaum lossis zes, so / tiv tauj cov ntsiab lus, thiab tuaj yeem suav nrog clamps, nres, nqus tsev, hlau nplaum, thiab pneumatics.

Q: Dab tsi yog Daim Ntawv Thov-Hloov Kho Fixtures?

A: Daim ntawv thov-hom kev kuaj xyuas lub zog ua haujlwm nyob rau hauv qhov sib txawv los ntawm qhov chaw ruaj khov kho. Es tsis txhob muaj cov khoom mounted rau cov fixtures, thov-hom fixtures mount ncaj qha mus rau lub Cheebtsam raug kuaj.

Qee qhov hnyav dua, zoo li cov hauv kev lag luam automotive, tsuas yog hnyav dhau los yuav tsum tau muab tso rau hauv qhov chaw sib tw. Txawm li cas los xij, txij li cov khoom tsim tsis raug tuaj yeem ua rau muaj qhov tsis zoo, cov chaw tsim khoom lag luam profile thiab tsim cov qauv tsim tshwj xeeb rau cov xwm txheej no nrog rau cov uas yuav tsum tau kuaj xyuas ntau dua thaum kawg ntawm cov txheej txheem tsim khoom.

Q: Dab tsi yog Kev Tshawb Fawb Hlau Sib Tw (PIMM) Fixtures?

A: Txawm hais tias feem ntau lwm cov khoom siv tau siv los tshuaj xyuas cov khoom ntawm tus kheej, piv txwv li, lub tsheb, lawv tsis haum rau kev tshuaj xyuas lub tsheb hauv nws cov theem pib ntawm kev tsim qauv. PIMM fixtures tiv thaiv tus nqi yuam kev thaum lub sij hawm prototyping, xyuas kom meej tias tag nrho cov ntawv hlau qhov chaw haum ua ke ntawm tus qauv qauv. Clamps thiab lwm yam fasteners ua hauj lwm yog siv rau txoj hauj lwm thiab ruaj ntseg cov qauv vaj huam sib luag rau tuav fixtures. Qhov no ua kom muaj qhov haum haum thaum lub sij hawm prototyping thiab dhau mus.

Q: Yuav ua li cas rau kev sib koom ua ke hlau sib txuam tshuaj xyuas Fixtures?

A: Lub CIMM tshuaj xyuas fixtures yog ua ke ntawm CMM thiab PIMM fixtures. Lawv feem ntau yog siv los kuaj xyuas qhov deformations tshwm sim los ntawm kev sib sau ua ke sib txawv ua ke, nrog rau CIMM fixture kuaj seb qhov deformation puas nyob rau hauv qhov kam rau ua.

Q: Dab tsi yog fixtures nyob rau hauv automotive kev lag luam?

A: Fixtures yog tuav cov khoom siv rau cov khoom siv hlau thiab feem ntau siv hauv kev lag luam tsheb. Fixtures tuav ib feem ntawm kev taw qhia tias nws yuav haum thaum nws nyob ntawm lub tsheb nws tus kheej.

Raws li ib qho ntawm cov kws tshaj lij kev kuaj xyuas fixture manufacturers thiab lwm tus neeg nyob hauv Suav teb, peb tau tshwj xeeb los ntawm cov khoom zoo thiab cov kev pabcuam zoo. Thov so assured mus yuav los yog lag luam wholesale bulk customized check fixture los ntawm peb lub hoobkas. Rau cov lus hais thiab qauv dawb, tiv tauj peb tam sim no.
